Copper Press Female Line Adaptor - Water

Copper Press Female Line Adaptor – Water

Elson Press fittings are manufactured by an ISO9001 accredited and certified factory. Elson is an established Australian-owned company with over 25 years of experience. These female line adaptors provide a secure and reliable connection for water applications, compatible with standard BSP fittings.

Key Features:

• Lead-Free DR Brass (<0.1% Pb)
• V-profile press design for leak-proof connections
• Leak-Before-Press O-ring ensures safety if not pressed
• German-certified high-quality O-ring material
• Flame-free press installation — no hot works required
• Compatible with BUSHPEX systems
• Complete certified and tested tooling range available
• Technical manuals and product information provided
• Nationwide after-sales and technical support

Variants:

• FKP437 — ELSON PRESS WATER FEMALE LINE ADAPTOR 12 X 12FI BSP EPW
• FKP439 — ELSON PRESS WATER FEMALE LINE ADAPTOR 20 X 20FI BSP EPW
• FKP441 — ELSON PRESS WATER FEMALE LINE ADAPTOR 25 X 25FI BSP EPW
• FKP443 — ELSON PRESS WATER FEMALE LINE ADAPTOR 32 X 32FI BSP EPW
• FKP445 — ELSON PRESS WATER FEMALE LINE ADAPTOR 40 X 40FI BSP EPW
• FKP447 — ELSON PRESS WATER FEMALE LINE ADAPTOR 50 X 50FI BSP EPW

Specifications:

• Material: Lead-Free DR Brass
• Suitable For: Potable water, water & solar applications
• Max Working Pressure: 1600 kPa
• Max Working Temperature: -20°C to 100°C
• Press Type: V-profile press
• Range: 12mm – 50mm
• Standards: ISO9001 Certified Manufacturing
• Warranty: 25-Year Product Warranty
• Installation: Flame-free press installation, no hot works required
